Name: Robotic Harmonic Drive Strain Wave Gears Reducer Cross Slider Type
Brand: Suzhou Giant Precision Industry Co., Ltd.
SKU: LSS-17-XX-U-II
Availability: InStock

Home > Products > Harmonic Drive >

Robotic Harmonic Drive Strain Wave Gears Reducer Cross Slider Type

Robotic wave gears

Cross Slider wave gears

Robotics harmonic drive strain wave gear

Place of Origin:

China

Brand Name:

Giant Precision

Certification:

ISO9001

Model Number:

LSS-17-XX-U-II

Request A Quote

Robotic Harmonic Drive Strain Wave Gears Reducer Cross Slider Type

Product Details

Model:

Product:

Model 17 Strain Wave Reducer

Components:

Wave Generator, Flexspline, Circular Spline

Reduction Ratio:

50:1, 80:1, 100:1, 120:1

Backlash:

≤20 Arc Sec

Maximum Input Speed:

7300 R/min

Design Life:

15000 Hours

Advantages:

High Torque Capacity, High Precision And Low Backlash

Weight:

0.67kg

Application:

Robotics, Aerospace, Medical Equipment, Industrial Machinery, Telecommunications, Renewable Energy

Warranty:

1 Year

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

To Be Negotiated

Packaging Details

Carton Box

Delivery Time

3-4 Weeks

Payment Terms

T/T

Supply Ability

20000 Sets per Month

Light Weight 2.47kg Model 32 Strain Wave Reducer Low Backlash Harmonic Gear Units

Get Best Price

Low Backlash And High Efficiency Model 25 Strain Wave Reducer Ultralight Harmonic Gear Units

Get Best Price

High Reduction Ratio LSN Series Model 20 Strain Wave Reducer 0.73kg Light Weight Gear Units

Get Best Price

Compact And Lightweight Design LSN Series Strain Wave Reducer Model 14 Gear Units

Get Best Price

Contact Now

Product Description

Robotic Harmonic Drive Strain Wave Gears Reducer Cross Slider Type 0

Application

Robotics

Industrial Robots: For precise movement and control in robotic arms, enabling accurate positioning and manipulation of objects in manufacturing and assembly lines.
Service Robots: Used in robots designed for tasks like cleaning, delivery, and personal assistance, where precise and reliable motion is essential.
Surgical Robots: In medical applications, such as robotic surgery, where extremely precise and smooth movements are crucial for successful outcomes.

Aerospace

Satellite Positioning: Used in the positioning and control of satellite components, where precision and reliability are critical.
Aircraft Control Systems: Employed in various control systems within aircraft to ensure precise movement and adjustments.

Model		17
Reduction ratio		50	80	100	120
Rated torque at 2000r/min input	Nm	16	22	24	24
Rated torque at 2000r/min input	kgfm	1.6	2.2	2.4	2.4
Permissible peak torque at start and stop	Nm	34	43	54	54
Permissible peak torque at start and stop	kgfm	3.5	4.4	5.5	5.5
Permissible maximum value for average load torque	Nm	26	27	39	39
Permissible maximum value for average load torque	kgfm	2.6	2.7	4	4
Permissible maximum momentary torque	Nm	70	87	108	86
Permissible maximum momentary torque	kgfm	7.1	8.9	11	8.8
Permissible maximum input rotational speed (Grease)	r/min	7300
Permissible average input rotational speed (Grease)	r/min	3500
Backlash	Arc Sec	≤20
Weight	kg	0.67
Design life	Hour	10000	15000	15000	15000

Robotic Harmonic Drive Strain Wave Gears Reducer Cross Slider Type 2

	Key Attributes of LSS - II Model 17 Harmonic Gear Units
	Product	Model 17 Harmonic Drive
	Components	Wave Generator, Flexspline, Circular Spline
	Reduction Ratio	50:1, 80:1, 100:1, 120:1
	Backlash	Less than 20 Arc Sec
	Average Input Speed	7300 r/min
	Max Input Speed	3500 r/min
	Design Life	15000 hours
	Model	17
	Weight	0.67 kg
	Warranty	1 Year
