WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function

WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function

Real Time Weighing Gripper

3C Electronics Weighing Gripper

High Precision Weighing Gripper

Place of Origin:

China

Brand Name:

Giant Precision

Certification:

ISO9001

Model Number:

WEPG Series

Contact Us
Request A Quote
WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function
Product Details
Product:
WEPG Series Weighing Gripper
Adapter Electric Grapper:
EPG 30-150
Body Weight:
2.5 KG
Gripping Force:
150 N
Adjustable Stroke:
30 Mm
Clamping Speed:
0.8s In 30mm
Maximum Weighing Range:
3 KG
Sensor Calibration Accuracy:
±1g
Installation Level:
＜±0.5°
Compliant With International Standards:
CE, RoHS
Communication Protocol:
EtherCAT
Usage Environment:
19 ℃± 3℃, Below 70% RH
Payment & Shipping Terms
Minimum Order Quantity
To Be Negotiated
Price
To Be Negotiated
Packaging Details
Carton Box
Delivery Time
3-4 Weeks
Payment Terms
T/T
Supply Ability
20000 Sets per Month
RELATED PRODUCTS
Good price Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries online video

Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries

Get Best Price
Good price WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function online

WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function

Get Best Price
Good price ERG - HP Series High Precision Rotary Gripper For 3C Electronics online

ERG - HP Series High Precision Rotary Gripper For 3C Electronics

Get Best Price
Good price ZRG Series Lifting And Rotating Gripper For 3C Electronics And Precision Manufacturing online video

ZRG Series Lifting And Rotating Gripper For 3C Electronics And Precision Manufacturing

Get Best Price
Contact Us
Contact Now
Product Description
WEPG Series
Weighing Gripper
WEPG series is a high-precision weighing gripper with real-time weighing function, ultra-high precision, safe and efficient, and intelligent clamping force control stroke feedback function.


WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function 0

   WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function 1 WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function 2
Integrated Drive and Control Grab Feedback Networking Applications



Adapter electric grapper EPG30-150 Installation level ＜±0.5°
Body weight 2.5kg Readability 0.1g
Gripping force 150N Supply voltage 24V
Adjustable stroke 30mm Peak current 1A
Clamping speed 0.8s in 30mm Communication protocol EtherCAT
Maximum weighing range 3kg Usage environment 19 ℃± 3℃, below 70% RH
Sensor calibration accuracy ±1g

Drawing
WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function 3Application



  • 3C Electronics
  • Auto Parts
  • Precision Manufacturing
  • Medical Aesthetics
  • Life Sciences
  • Education and Research
