A rotate vector (RV) reducer is a type of speed reducer which forms the core component of most advanced robots. Compared to other gear reducers, it has higher precision, better reliability, increased efficiency and is smaller in size.
RV reducers main purpose is to make the paint thin enough to spray through a gun as well as providing leveling of the paint and adhesion. They are made up of a combination or blend of different solvents.
Key Features
1. Compact Design: RV reducers are known for their compactness, making them suitable for applications where space is limited.
2. High Gear Reduction Ratio: They offer high gear reduction ratios in a relatively small package, providing precise control and high torque output.
3. Zero Backlash: One of the key features of RV reducers is their zero-backlash operation, ensuring accurate positioning and smooth motion transmission.
4. High Precision: RV reducers provide high precision and repeatability, making them suitable for applications that require precise motion control.
Specifications
Parameters table of RV - F series
| Output Speed(r/min) | 15 | Flexural rigidity (reference value) | Allowable flexural torque | Momentary max. allowable flexural torque |
Allowable acceleration/ deceleration torque |
Momentary max. allowable torque |
Angular transmission error | Backlash | Gear backlash | Torsional rigidity(reference value) | Allowable thrust load | ||
| Model | Reduction ratio of a single reducer unit | Output torque | Input power | ||||||||||
| Nm(kgf-m) | kW | Nm/arc.min. (kgf-m/ arc.min.) | Nm(kgf-m) | Nm(kgf-m) | Nm(kgf-m) | Nm(kgf-m) | MAX.Arc.min. | MAX.Arc.min. | MAX.Arc.min. | Nm/arc.min. (kgf-m/Arc.min.) | N(kgf) | ||
| BX550F | 40 | 5390 | 11.3 | 9100 (928) |
10780 (1100) |
21560 (2200) |
13475 (1375) |
26950 (2750) |
1 | 1 | 1 | 1666 (170) |
31360 (3200) |
| BX700F | 200.33 | 6860 | 14.4 | 12700 (1296) |
15000 (1530) |
30000 (3061) |
17150 (1750) |
34300 (3500) |
1 | 1 | 1 | 2120 (216) |
44000 (4489) |
| 250.6 | |||||||||||||
| Key Attributes of RV - F Series RV Reducer | |||
| Product | High Precision RV Reducer | ||
|
Material
|
Steel, Aluminum | ||
|
Output torque
|
5390 to 6860 Nm | ||
| Output speed | 15 r/min | ||
|
Backlash
|
MAX. 1 Arc.min. |
||
|
Momentary max. allowable torque
|
26950 to 34300 Nm | ||
|
Lost motion
|
MAX. 1 Arc.min. | ||
|
Model
|
BX550F, BX700F |
||
| Color | Sliver | ||
| Warranty | 1 year | ||
Application
