Place of Origin:
China
Brand Name:
Giant Precision
Certification:
ISO9001
Model Number:
EVS Series
|
|
|
|
IP40 Protection Level
|
Grab Feedback | Power Outage Pressure Maintenance |
| Product overview | ||
|
|
|
|
model
|
EVS01
|
EVS08
|
|
vacuum degree
|
10%-60%
|
10%-70%
|
|
Maximum flow rate
|
2.5 L/min
|
10L/min
|
|
Body weight
|
0.3 kg
|
1.4kg
|
|
*Maximum recommended load
|
1kg
|
8 Kg
|
|
Fastest adsorption time
|
0.1 s
|
0.4s
|
|
Fastest release time
|
0.1 s
|
0.2s
|
|
Protection level
|
IP40
|
IP54
|
|
Usage environment
|
0-40 ℃, below 85% RH
|
0-40 ℃, below 85% RH
|
|
Operating noise
|
＜70dB
|
＜70dB
|
|
Rated voltage
|
DC 24V±10%
|
DC 24V±10%
|
|
Rated current
|
0.13A
|
0.5A
|
|
peak current
|
0.3A
|
3.8A
|
|
Compliant with international standards
|
CE,RoHS
|
CE,RoHS
|
|
Communication protocol
|
Modbus RTU(RS485) Digital I/O
|
Modbus RTU(RS485) Digital I/O
|
| Application |
