Place of Origin:
China
Brand Name:
Giant Precision
Certification:
ISO9001
Model Number:
EVS Series
Our standard parallel grippers include small parts, universal, long-stroke, and sealed grippers for safe and precise handling of workpieces. They can handle workpieces with weights of anywhere between a few grams and large kilograms, and are suitable for many applications, from the cleanroom to potentially explosive work areas.
The ability to equip the grippers with inductive sensor systems, magnetic switches or workpiece-specific gripper fingers improves their functionality, process reliability, and productivity. Furthermore, innovative design tweaks, such as multi-tooth guidance, are combined with state-of-the-art production technology to make them robust and reliable and therefore safe investment with a long service life.
|
|
|
|
IP40 Protection Level
|
Grab Feedback | Power Outage Pressure Maintenance |
| Product overview | ||
|
|
|
|
model
|
EVS01
|
EVS08
|
|
vacuum degree
|
10%-60%
|
10%-70%
|
|
Maximum flow rate
|
2.5 L/min
|
10L/min
|
|
Body weight
|
0.3 kg
|
1.4kg
|
|
*Maximum recommended load
|
1kg
|
8 Kg
|
|
Fastest adsorption time
|
0.1 s
|
0.4s
|
|
Fastest release time
|
0.1 s
|
0.2s
|
|
Protection level
|
IP40
|
IP54
|
|
Usage environment
|
0-40 ℃, below 85% RH
|
0-40 ℃, below 85% RH
|
|
Operating noise
|
＜70dB
|
＜70dB
|
|
Rated voltage
|
DC 24V±10%
|
DC 24V±10%
|
|
Rated current
|
0.13A
|
0.5A
|
|
peak current
|
0.3A
|
3.8A
|
|
Compliant with international standards
|
CE,RoHS
|
CE,RoHS
|
|
Communication protocol
|
Modbus RTU(RS485) Digital I/O
|
Modbus RTU(RS485) Digital I/O
|
| Application |
