Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries

Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries

Heavy Duty Electric Parallel Grippers

Lithium Batteries Electric Parallel Grippers

LEPG Series Electric Parallel Grippers

Place of Origin:

China

Brand Name:

Giant Precision

Certification:

ISO9001

Model Number:

LEPG Series

Contact Us
Request A Quote
Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries
Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries
Product Details
Model:
LEPG70-500
Adjustable Stroke:
0-70mm
Single Finger Gripping Force:
40-500N
Open/Close Time:
0.9s
Position Repeatability:
±0.02mm
Maximum Recommended Load:
10kg
Collision Buffer:
Optional
Collision Detection:
Support X/Y/Z Direction Detection
Drop Detection:
Support
Power-off Retention:
Support
Power-off Memory:
Support
Weight:
3 Kg
IP Rating:
IP43
Communication Protocol:
Modbus RTU(RS 485) Digital I/O
Payment & Shipping Terms
Minimum Order Quantity
To Be Negotiated
Price
To Be Negotiated
Packaging Details
Carton Box
Delivery Time
3-4 Weeks
Payment Terms
T/T
Supply Ability
20000 Sets per Month
RELATED PRODUCTS
Good price Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries online video

Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries

Get Best Price
Good price WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function online

WEPG Series High-Precision Weighing Gripper For 3C Electronics With Real - Time Weighing Function

Get Best Price
Good price ERG - HP Series High Precision Rotary Gripper For 3C Electronics online

ERG - HP Series High Precision Rotary Gripper For 3C Electronics

Get Best Price
Good price ZRG Series Lifting And Rotating Gripper For 3C Electronics And Precision Manufacturing online video

ZRG Series Lifting And Rotating Gripper For 3C Electronics And Precision Manufacturing

Get Best Price
Contact Us
Contact Now
Product Description

LEPG Series Heavy-Duty

Electric Parallel Grippers
In the production process, there are multiple scenarios that require the use of robots for loading and unloading. Junduo has a deep understanding of market demand and industry pain points and has developed a variety of electric grippers suitable for the industry, which can be used in lithium batteries, 3C, precision manufacturing, electrical appliances, automobile manufacturing, medical equipment, new energy and other industries.


Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries 0

   Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries 1 Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries 2
Integrated Drive and Control Grab Feedback Networking Applications

Product Parameters

Model LEPG70-500
Adjustable stroke 0-70mm
Single finger gripping force 40-500N
Open/Close Time 0.9s
Position repeatability ±0.02mm
*Maximum recommended load 10kg
Collision buffer Optional
Collision Detection Support X/Y/Z direction detection
Drop detection support
Power-off retention support
Power-off memory support
Weight 3 kg
IP Rating IP43
Rated voltage DC 24±10% V
Maximum current 2 A
Rated current 0.6 A
Communication Protocol Modbus RTU(RS 485) Digital I/O
Comply with international standards CE,RoHS
Permissible static load in vertical direction Fz 1000 N
Allowable static moment of slider Mx 200 N·m
Allowable static moment of slider My 150 N·m
Allowable static moment of slider Mz 150 N·m


Application

  • Lithium battery
  • 3C
  • Precision Manufacturing
  • Electrical appliances
  • Automotive
  • Medical Devices
  • New Energy
Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries 3 Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries 4 Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries 5 Heavy Duty LEPG Series Electric Parallel Grippers For Robots In Lithium Batteries 6
3C Electronics Automation Equipment Robot Medical Automation
